Nursing Home - Residential Unit Plan

Nursing Home - Residential Unit Plan

Create floor plan examples like this one called Nursing Home - Residential Unit Plan from professionally-designed floor plan templates. Simply add walls, windows, doors, and fixtures from SmartDraw's large collection of floor plan libraries.

Text in this Example:

2nd Floor
Courtyard
Nursing Home Residential Unit Plan
1. Administration
2. Lounge
3. Nurse Station
4. Pharmacy
5. Medical/service
6. Laundry
7. Living/Dining Room
8. Sunroom
9. Employee Facilities
not to scale
