Easy Scaled Drawings Without CAD Complexity

Drag and Drop Rooms and Floor Plan Elements

Drag and drop rooms to your floor plan and snap them together without overlapping. Add new elements like doors, windows, appliances, fixtures, and furniture easily from SmartDraw's vast collection of industry-standard content.

Industry-Standard Content

Get thousands of industry-standard symbols to build anything from commercial floor plans, warehouse layouts to accident reconstructions and fire pre-plans.

Add Walls Easily

Click. Drag. Done. You can create any layout using walls that join easily and always snap to 90 degrees.

Add Corners and Alcoves Instantly

Create alcoves instantly. SmartDraw's Add Wall Segment command expands a room outward by automatically adding two perpendicular wall segments with no manual drawing required.

Resize Elements by Typing

When you need pinpoint accuracy, you can resize any object or wall by simply typing in the exact dimensions. Just select the item, click on the displayed measurement, and enter your desired value.

You can also adjust the angles between walls by typing. Just enter the exact angle you want and the walls will adjust automatically. With SmartDraw, it's easy to look like an expert without being one.

Take the Guesswork Out of Positioning

SmartDraw makes placing doors and windows precise and effortless. See real-time distances as you move openings into place or type in the exact measurement on the wall to meet real-world conditions or building codes. Get an inch-perfect, polished design quickly and easily.

Built-In Measurement Guides

As you drag elements to your floor plan, SmartDraw's automatic blue guides will show you the distance to the nearest wall or object. You'll know exactly where to place new items so things are aligned and evenly spaced. You can also measure distance or measure area with built-in tools at any time.
